How to Build a RAG Application with LangChain + Pinecone (2026 Tutorial)

This is a hands-on tutorial for building a working retrieval-augmented generation application with LangChain and Pinecone. By the end, you will have a Python script that loads a folder of documents, embeds them, stores the vectors in Pinecone, and answers questions grounded in your own content. The whole thing takes under 100 lines of code and about 20 minutes.

What you will build

A command-line Q&A tool that reads a folder of PDFs or Markdown files, builds a searchable vector index on Pinecone, and answers questions with citations back to the source documents. The same pattern underpins most “chat with your docs” products shipping in 2026, including internal support bots, documentation assistants, and legal research tools.

Stack:

• Python 3.10 or newer
• LangChain 0.3 with the langchain-openai and langchain-pinecone packages
• Pinecone Serverless (free tier is enough for this tutorial)
• OpenAI API for embeddings (text-embedding-3-small) and generation (gpt-4o)

Prerequisites and setup

You need API keys for OpenAI and Pinecone. Both have free sign-up and both free tiers cover this tutorial comfortably.

Create a new project folder and set up a virtual environment:

mkdir rag-tutorial && cd rag-tutorial
python -m venv .venv
source .venv/bin/activate  # Windows: .venv\Scripts\activate
pip install langchain langchain-openai langchain-pinecone langchain-community pypdf python-dotenv

Create a .env file in the project folder with your keys:

OPENAI_API_KEY=sk-...
PINECONE_API_KEY=pcsk_...

Make a docs/ folder next to your script and drop a few PDFs or Markdown files in it. For the first run, three or four files of under 20 pages each is plenty to see the system work.

Step 1: Load documents

LangChain’s community loaders handle most file formats. For PDFs plus Markdown, the DirectoryLoader with glob patterns is the simplest way:

from langchain_community.document_loaders import DirectoryLoader, PyPDFLoader, TextLoader

pdf_loader = DirectoryLoader("./docs", glob="**/*.pdf", loader_cls=PyPDFLoader)
md_loader = DirectoryLoader("./docs", glob="**/*.md", loader_cls=TextLoader)
documents = pdf_loader.load() + md_loader.load()
print(f"Loaded {len(documents)} document pages")

Each PDF page becomes its own document in LangChain. A 50-page handbook turns into 50 documents, each with metadata including the source file path and page number.

Step 2: Split into chunks

LLMs cannot read a whole 50-page document per query, and embedding a whole page produces a vector that averages too many topics together. Split documents into chunks of 500 to 1000 characters with some overlap so you do not lose context across chunk boundaries.

from langchain_text_splitters import RecursiveCharacterTextSplitter

splitter = RecursiveCharacterTextSplitter(
    chunk_size=800,
    chunk_overlap=100,
    separators=["\n\n", "\n", ". ", " ", ""],
)
chunks = splitter.split_documents(documents)
print(f"Split into {len(chunks)} chunks")

The RecursiveCharacterTextSplitter tries each separator in order, so it prefers to break on paragraph boundaries before sentence boundaries before raw character counts. For most content this produces clean, semantically coherent chunks.

Step 3: Create the Pinecone index

You create the index once, then upsert vectors into it. In 2026 the dimension for OpenAI’s text-embedding-3-small is 1536:

from pinecone import Pinecone, ServerlessSpec
import os
from dotenv import load_dotenv

load_dotenv()
pc = Pinecone(api_key=os.environ["PINECONE_API_KEY"])

INDEX_NAME = "rag-tutorial"
if INDEX_NAME not in [i["name"] for i in pc.list_indexes()]:
    pc.create_index(
        name=INDEX_NAME,
        dimension=1536,
        metric="cosine",
        spec=ServerlessSpec(cloud="aws", region="us-east-1"),
    )
    print(f"Created index: {INDEX_NAME}")

Serverless indexes bill per read, per write, and per GB stored, which keeps the free tier free until you have hundreds of thousands of chunks. For this tutorial you will spend $0.

Step 4: Embed and upsert the chunks

LangChain’s PineconeVectorStore wraps the embedding and upsert work into one call:

from langchain_openai import OpenAIEmbeddings
from langchain_pinecone import PineconeVectorStore

embeddings = OpenAIEmbeddings(model="text-embedding-3-small")
vector_store = PineconeVectorStore.from_documents(
    documents=chunks,
    embedding=embeddings,
    index_name=INDEX_NAME,
)
print("Embeddings uploaded to Pinecone")

This single call sends each chunk to OpenAI for embedding, then uploads the resulting vectors to Pinecone with metadata (source file, page number, chunk index). For 500 chunks on a decent internet connection, expect under a minute.

Step 5: Build the query chain

Now you connect the vector store to an LLM through a retrieval chain:

from langchain_openai import ChatOpenAI
from langchain.chains import RetrievalQA

retriever = vector_store.as_retriever(search_kwargs={"k": 4})
llm = ChatOpenAI(model="gpt-4o", temperature=0)
qa = RetrievalQA.from_chain_type(
    llm=llm,
    retriever=retriever,
    return_source_documents=True,
)

while True:
    question = input("\nAsk a question (or 'quit'): ").strip()
    if question.lower() in ("quit", "exit", ""):
        break
    result = qa.invoke({"query": question})
    print(f"\nAnswer: {result['result']}")
    print("\nSources:")
    for doc in result["source_documents"]:
        source = doc.metadata.get("source", "unknown")
        page = doc.metadata.get("page", "?")
        print(f"  {source} (page {page})")

Save this all as rag.py and run python rag.py. Ask it questions grounded in your documents. The system retrieves the top four most similar chunks, feeds them to GPT-4o as context, and returns an answer with the source file and page number for each chunk used.

What to tune first when results are off

Your first run will not be perfect. Here is the order of knobs to try:

• Chunk size: if answers feel incomplete, increase chunk_size to 1200. If they wander, decrease to 500.
• Top-k retrieval: raise k from 4 to 8 if the model is missing context. Lower k to 2 if it is adding irrelevant filler.
• Embedding model: text-embedding-3-small is cheap but limited. text-embedding-3-large (3072 dim) catches more subtle semantic matches but needs a new Pinecone index with the matching dimension.
• Metadata filters: restrict retrieval to a subset of your corpus by filtering on metadata (for example, only match chunks from the 2024 handbook).
• LLM temperature: already at 0 above, which minimizes hallucination. Leave it there.

Shipping to production

The tutorial script runs locally. For a real app:

• Separate indexing (slow, batch) from querying (fast, user-facing). Run indexing on a schedule or on upload events, not on every query.
• Wrap the query chain in a FastAPI or Next.js API route and stream the answer with LangChain’s streaming support.
• Add observability with LangSmith or OpenTelemetry. You want to see what chunks are being retrieved for every question.
• Set up evaluation. A small test set of 20 to 50 real questions with known-good answers lets you measure drift when you change prompts or models.
